20 Heads Combination Weigher 20H1.6L
20 Heads Combination Weigher 20H1.6L
Contact us for price
Location:Ontario, CA
or
Call +1(626)3202070
Description
Main Features
- Modular control system for easier troubleshooting and lower repair costs.
- Multi-language HMI available.
- The load cell and photoelectric sensors detect the material feed quantity.
- Equipped with sequential discharge function to prevent material blockage.
- Production records can be checked and downloaded to PC.
- Material-contact parts can be easily removed for cleaning without tools.
Specifications
| Manufacturer | Hongda |
| Model | 20H1.6L |
| Year | 2025 |
| Condition | New |
| Stock Number | 163 |
| Weighing Head | 20 |
| Weighing Range | 0.35–105.8 oz (10–3000g) |
| Bucket Capacity | 0.42 gal (1.6L) |
| Operation Panel | 10 inch touch screen |
| Power Supply | 200-240Vac,50/60Hz,3KW |
| Drive System | Step Motor |
| Material Contact Surfaces | 304 stainless steel with a patterned plate |
| Vibratory Main Feeder | Single main vibration |
| Discharge Outlet | Single discharge outlet |
| Packing Dimensions | 90.6″(L) × 60.2″(W) × 67.7″(H) |
| Gross Weight | 1,984 lbs |
