Automatic Cartoning Machine 250
Automatic Cartoning Machine 250
Contact us for price
Location:Ontario, CA
or
Call +1(626)320-2070
Description
Application
- Pharmaceuticals in aluminum-plastic blister packs, medicine bottles, cosmetics, food, and other similar items.
Features
- Efficient Operation: Intermittent motion design with PLC control ensures smooth, reliable cartoning with minimal maintenance.Automatically completes box feeding, opening, and sealing.
- High Productivity: Delivers fast cartoning speed with low mechanical wear, maximizing output while reducing operating costs.
- Precise Carton Opening: Automatic vacuum carton pick-up with wide-angle opening for accurate and consistent box forming.
- Product Protection: Intermittent infeed system with overload protection guarantees safe product insertion.
- Flexible & Easy to Adjust: Quick changeover for different product sizes with minimal part replacement. Multiple carton-closing options available.
- Safety Assured:
- No carton: No product insertion; automatic stop with audible alarm.
- No product: Carton held with audible alarm.
Specifications
| Model | 250 |
| Year | 2025 |
| Condition | New |
| Stock Number | 199 |
| Cartoning Speed | 30–70 cartons/min |
| Carton Quality Requirement | 250–350 g/m² (depending on carton size) |
| Carton Length | 2.75–9.45 in (70–240 mm) |
| Carton Width | 0.98–5.51 in (25–140 mm) |
| Carton Height | 0.59–2.36 in (15–60 mm) |
| Good Product Rate | 99% (depending on carton and product fit) |
| Machine Utilization | 90% (depending on carton and product fit) |
| Damage Rate | 0.3% |
| Machine Dimensions | 110×41×67 in |
| Air Consumption | ≥5.3 SCFM (≥150 L/min, ANR) |
| Compressed Air Pressure | 72.5–101.5 psi (0.5–0.7 MPa) |
| Power Supply | 220Vac,50/60Hz,0.75Kw |
