M-type Bag Packaging Machine RZ10-M190
M-type Bag Packaging Machine RZ10-M190
Contact us for price
Location:Ontario, CA
or
Call +1(626)320-2070
Specifications
| Manufacturer | Hongda |
| Model | RZ10-M190 |
| Year | 2026 |
| Condition | New |
| Stock Number | 1 |
| Model | RZ10-M190 |
| Applicable Bag Type | Gusseted Pouch |
| Working Process | 10 Stations: 1. Bag feeding (angled) 2. Date coding 3. Bag opening 4. Filling (1st) 5. Filling (2nd) 6. Pre-sealing 7. Pre-sealing 8. Heat sealing 9. Heat sealing 10. Shaping & vertical discharge |
| Bag Size | Width: 80–190 mm Length: 80–370 mm Gusset ≤ 50 mm |
| Filling Range | ≤ 500 g; 500–1000 g |
| Packaging Speed* | 30–40 bags/min (≤500g); 15–30 bags/min (500–1000g) *Speed depends on product characteristics and packaging conditions.) |
| Machine Weight | Approx. 2000 kg |
| Machine Dimensions (L×W×H) | 2260 × 1950 × 1550 mm (including feet and casters) |
| Total Power | 4.12 kW (dual heating, excluding vacuum pump) |
| Power Supply | 380V, 3-phase, 5-wire, 50 Hz (customizable) |
| Air Consumption | ≥ 0.5 m³/min (compressed air supplied by customer) |
